The Jetson Nano™ Developer Kit delivers the compute performance to run modern AI workloads at unprecedented size, power, and cost. Developers, learners, and makers can now run AI frameworks and models for applications like image classification, object detection, segmentation, and speech processing.
The developer kit can be powered by micro-USB and comes with extensive I/Os, ranging from GPIO to CSI. This makes it simple for developers to connect a diverse set of new sensors to enable a variety of AI applications. It’s incredibly power-efficient, consuming as little as 5 watts.
Jetson Nano is also supported by NVIDIA JetPack, which includes a board support package (BSP), Linux OS, NVIDIA CUDA®, cuDNN, and TensorRT™ software libraries for deep learning, computer vision, GPU computing, multimedia processing, and much more. The software is even available using an easy-to-flash SD card image, making it fast and easy to get started.
The same JetPack SDK is used across the entire NVIDIA Jetson™ family of products and is fully compatible with NVIDIA’s world-leading AI platform for training and deploying AI software. This proven software stack reduces complexity and overall effort for developers.
Tip
The Raspberry Pi Camera Module V2 can work with Jetson Nano well, it will be a perfect camera in your AI project.
Key Features
Jetson Nano Module
> 128-core NVIDIA Maxwell™ GPU
> Quad-core ARM® A57 CPU
> 4 GB 64-bit LPDDR4
> 10/100/1000BASE-T Ethernet
Power Options
> Micro-USB 5V 2A
> DC power adapter 5V 4A
I/O
> USB 3.0 Type A
> USB 2.0 Micro-B
> HDMI/DisplayPort
> M.2 Key E
> Gigabit Ethernet
> GPIOs, I2 C, I2 S, SPI, UART
> MIPI-CSI camera connector
> Fan connector
> PoE connector
Kit Contents
> NVIDIA Jetson Nano module and carrier board
> Quick Start Guide and Support Guide
JETSON NANO DEVELOPER KIT
TECHNICAL SPECIFICATIONS
| DEVELOPER KIT | |
| GPU | 128-core Maxwell |
| CPU | Quad-core ARM A57 @ 1.43 GHz |
| Memory | 4 GB 64-bit LPDDR4 25.6 GB/s |
| Storage | microSD (not included) |
| Video Encoder | 4K @ 30 | 4x 1080p @ 30 | 9x 720p @ 30 (H.264/H.265) |
| Video Decoder | 4K @ 60 | 2x 4K @ 30 | 8x 1080p @ 30 | 18x 720p @ 30| (H.264/H.265) |
| Camera | 1x MIPI CSI-2 DPHY lanes |
| Connectivity |
